Equipment Parameters:
1. Dimensions (Length × Width × Height): 0.8m × 0.9m × 0.7m; Weight: 60KG
2. Power Supply and Power: 220V/50HZ; 2KW
3. Compressed Air Pressure for Use: 0.5-0.8Mpa; Air Consumption: 0.5m³/min
4. Noise ≤ 85dB
Number | Name of Spare Part | Quantity | Configuration Brand/Model/HeatTreatment |
| 1 | PLC Programmable Controller | 1set | Weisheng Industrial Control |
| 2 | Touch Screen | 1set | Kunlun |
| 3 | AC Contactor | 1set | Chint |
| 4 | Switch Electronic Components | Partially | Chint |
| 5 | Filling Servo Motor | 1set | Dingshi |
| 6 | Main Machine Servo Motor 750W | 1set | Dingshi |
| 7 | Capping Servo Motor | 1set | Dingshi |
| 8 | High Precision Planetary Reducer | 1set | Zhuolan |
| 9 | Detection Switch | 2set | Hugong |
| 10 | Pneumatic Components | The whole machine | Jiede |
| 11 | DC24V Power Supply Box | 1set | Mean Well (Taiwan) |
| 12 | Bearings | 2set | Haerbing |
| 13 | Frame Made of 304 Sheet Metal | The whole machine | SUS304 |
| 14 | Aluminum Parts | The whole machine | National Standard 6061 + Sandblasting Anodizing Treatment |
| 15 | Plastic Parts | Partially | PE、POM、or Teflon |
| 16 | Some Transmission Parts and Guide Parts | The whole machine | 304# |
